Resin Infusion flow media for the production of big-sized composites elements, such as wind blades
Engineering & Geosynthetics Fabric
Infusion Net / Mesh

Vacuum Infusion Mesh / Resin Infusion mesh (also know as Flow Media) is responsible for the even flow of resin during vacuum infusion process. It can also be used to increase the speed of resin flow in selected areas.

Our infusion mesh is really easy to flat out and suitable for moulding any shape and size. We have two types of Infusion mesh.

Product Highlights:


  • Even hole
  • Stable performance
  • Strict structure
  • Good toughness
  • Lightweight
  • Shock resistance

Specifications


Extruded Resin Infusion Mesh

MaterialPolyethylene
Width1.2 meters / 1.5 meters
Max Working Temperature120°C
Weight 160 to 260 gsm
Colour Green / White / Transparent
Length per roll 25 / 50 / 100 meters

Woven Resin Infusion Mesh

MaterialPolyethylene
Width2 meters / 4 meters / 6 meters
Max Working Temperature120°C
Weight 150 to 180 gsm
Colour Green / White / Transparent etc
Length per roll 50 meters / 100 meters
Softer than the extruded mesh, hence more suitable for using on complex shapes
